Description
Bently Nevada 106765-16 Coaxial Interconnect Cable
Precision-engineered in USA for critical signal transmission. Features BNC connectors and 75Ω impedance for superior EMI resistance in industrial environments.
SUFFIX BREAKDOWN
- ► 106765 (Base Series)
- │─ Coaxial construction
- │─ Industrial-grade materials
- ► -16 (Configuration)
- │─ 16ft length (4.88m)
- │─ BNC Male to BNC Male
- └─ 75Ω impedance
KEY FEATURES
- 75Ω impedance for signal integrity
- Corrosion-resistant BNC connectors
- Wide temperature range: -40°C to 85°C
- Low capacitance design (45pF/ft)
TECHNICAL SPECIFICATIONS
| Electrical | Impedance: 75Ω | Max Voltage: 300V |
| Mechanical | Connectors: BNC Male/BNC Male | Bend Radius: 60mm |
| Environmental | Temp Range: -40°C to 85°C | Vibration: 5g max |
| Physical | Length: 4.88m | Weight: 0.23kg | Diameter: 6.5mm |
INSTALLATION GUIDE
- Hand-tighten BNC connectors until snug
- Maintain minimum 60mm bend radius
- Use drip loops in vertical runs
- Test continuity with multimeter
COMPATIBILITY
- Bently Nevada 3500 monitoring systems
- Oscilloscopes & spectrum analyzers
- CCTV and video monitoring equipment
- RF test instrumentation
PACKAGE CONTENTS
- 1 × 16ft coaxial cable (106765-16)
- 2 × Dust protection caps
- Installation guide
SHIPPING & WARRANTY
- Made in USA
- Ships via FedEx/UPS/DHL
- 12-month manufacturer warranty
- Custom connector options available
FAQ
Q: What’s the difference between 50Ω and 75Ω cables?
A: 75Ω (like this cable) is ideal for video/RF. 50Ω is better for data transmission.
Q: Can I use this outdoors?
A: Yes. UV-resistant jacket rated for outdoor use.
Q: Are torque tools required for connectors?
A: No. Hand-tightening provides secure connection.
