Description
Bently Nevada 330702-00-24-10-01-05 Proximity Sensor – Multi-Certified Industrial Solution
1-meter armored vibration probe with global approvals. Features connector protection and extreme environment durability. Made in USA.
Complete Specifications
- Brand: Bently Nevada
- Model: 3300 XL 11mm Probe
- Full Part: 330702-00-24-10-01-05
- → 00: 0″ unthreaded section
- → 24: 2.4″ case length
- → 10: 1.0 meter cable
- → 01: ClickLoc with protector
- → 05: Multiple approvals
- Resistance: 5.9Ω ±0.5
- Temp Range: -51°C to +177°C
- Bend Radius: 25.4mm minimum
- Thread: 1/2-20 UNF
Installation Guide
- Max Torque: 45.2 N•m (400 in•lb)
- Safe Torque: 15.2 N•m (133 in•lb)
- Finger-tight connector installation only
- Viton O-ring seals pressure differences
Shipping & Warranty
- Global express: FedEx, UPS, DHL
- Package weight: 0.17kg
- Full 12-month warranty
Technical Questions
- Q: Which certifications are included?
A: Multiple global approvals – contact for specifics - Q: Why use connector protector?
A: Prevents damage in high-vibration areas - Q: Minimum installation clearance?
A: 2.4″ case length needs minimal space - Q: Pressure rating for O-ring?
A: Not rated – custom testing available - Q: Cable repair options?
A: Entire probe assembly replacement required
