Description
Bently Nevada 330702-00-10-10-12-00 – Precision 11mm Mini Probe
Compact Bently Nevada 3300 XL 11mm sensor with 1m cable. Made in USA. Works in extreme cold down to -51°C. Includes 12-month warranty.
Part Number Details
- ▸ 330702 = 11mm Probe Base
- ▸ -00 = 0″ unthreaded length
- ▸ -10 = 1.0″ case length
- ▸ -10 = 1.0 meter cable
- ▸ -12 = Mini ClickLoc connector
- ▸ -00 = No agency approvals
Technical Specifications
- Size: 11mm diameter
- Resistance: 5.9 Ω ±0.5 Ω
- Temp Range: -51°C to +177°C
- Cable Type: Triaxial FluidLoc
- Bend Radius: 25.4mm (1.0 in)
- Weight: 0.17kg (ultra-light)
Installation Guide
- Max torque: 15.2 N•m (133 in•lb)
- Thread: 1/2-20 UNF
- Connector torque: Finger tight
- Seal: Viton O-ring
Shipping & Support
- ???? Original factory packaging
- ✈️ Worldwide: FedEx/UPS/DHL
- ????️ 12-month product warranty
- ???????? Made in USA
Expert Questions
- Q: Minimum temperature limit?
A: -51°C (-60°F) continuous operation - Q: Seal material type?
A: Viton O-ring for pressure sealing - Q: Weight compared to 50mm probe?
A: 70% lighter (0.17kg vs 0.45kg) - Q: Cable length options?
A: 1m standard (5m/9m available) - Q: Pressure testing included?
A: No – contact for custom testing
0.0 Average Rating Rated (0 Reviews)
