Description
Bently Nevada 330707-00-10-90-01-05 Proximity Probe
Long-reach 9.0m industrial sensor with multi-agency approvals. Made in USA for precision monitoring.
Product Configuration
Brand: Bently Nevada
Model: 3300 XL 11mm Probe
Full ID: 330707-00-10-90-01-05
Part Number Details:
- Base: 330707 (5/8-18 UNF no armor)
- Unthreaded: 00 = 0 inch
- Case: 10 = 1.0 inch
- Cable: 90 = 9.0 meters
- Connector: 01 = ClickLoc with protector
- Certification: 05 = Multiple approvals
Technical Specifications
- Resistance: 8.5Ω ±1.1Ω
- Temperature range: -51°C to +177°C
- Min bend radius: 25.4mm
- Thread engagement: 0.938 inch max
- Torque max: 45.2 N•m (400 in•lb)
- Cable type: 75Ω triaxial FEP
- Seal material: Viton O-ring
- Cold limit: Do not store below -34°C
- Weight: 0.17 kg
- Tip material: PPS polymer
Installation Guide
- Use finger-tight connections
- Maintain 25.4mm cable bend radius
- Max thread engagement: 0.938 inch
- Protect from temperatures below -34°C
Package & Support
- New probe in factory packaging
- 12-month warranty coverage
- Worldwide shipping options
Technical Questions
Q: Cable length options available?
A: 1m, 5m or 9m configurations
Q: UNF thread size meaning?
A: Unified National Fine (5/8-18)
Q: Triaxial cable benefits?
A: Extra noise protection in factories
Q: Minimum storage temperature?
A: -51°C but avoid below -34°C
Q: Warranty coverage?
A: 12 months against defects
