Description
Bently Nevada 11mm Vibration Sensor: Industrial Machine Health Monitor
Precision proximity probe for critical equipment protection. Made in USA with durable materials.
Product Details
- Complete Model: 330707-00-24-90-12-00
- Sensing Tip: 11mm PPS material
- Thread Type: 5/8-18 UNF
- Cable Length: 9.0 meters (29.5 ft)
- Seal Material: Viton O-ring
Technical Specifications
- Brand: Bently Nevada
- Type: 3300 XL Proximity Probe
- Part Number: 330707-00-24-90-12-00
- Temperature Range: -51°C to +177°C
- Case Material: AISI 304 Stainless Steel
- Cable Type: 75 Ω triaxial FEP
- Resistance: 8.5 ± 1.1 ohms
- Weight: 0.17 kg
Suffix Breakdown
- 330707: 11mm Probe without armor
- 00: 0″ unthreaded length
- 24: 2.4″ case length
- 90: 9.0 meter cable
- 12: ClickLoc connector
- 00: No agency approvals
Key Performance Data
- Max Thread Engagement: 0.938 inch
- Recommended Torque: 15.2 N•m
- Min Bend Radius: 25.4 mm
- Cable Protection: FluidLoc technology
- Seal Warning: Avoid below -34°C
Compatibility
- Works with all 3300 XL monitoring systems
- Standard 5/8-18 UNF mounting
- ClickLoc connector compatible
Included in Package
- 1x Vibration probe
- 12-month warranty
Expert FAQs
- Q: What cable protection does this model have?
A: Features FluidLoc cable for moisture resistance - Q: Is this model agency certified?
A: No, option 00 indicates no certifications (330707-00-24-90-12-00) - Q: Can I use this in high-temperature environments?
A: Yes, rated up to +177°C (350°F) - Q: What’s the minimum bend radius?
A: 25.4mm (1 inch) to prevent cable damage - Q: How is the probe sealed?
A: Viton O-ring provides pressure sealing
