Description
Description
The Schneider Modicon Quantum 140CPU11303 is a powerful processor designed for use in the Modicon Quantum automation platform. This reliable and efficient processor provides robust processing power for industrial applications. Equipped with 368 kB of internal RAM, it supports extensive I/O configurations and offers flexible communication options, including Modbus RS232 and Modbus Plus. With a clock frequency of 20 MHz and a battery life of up to 10 years, this processor ensures long-term reliability in demanding environments.
Technical Specifications
- Brand: Schneider Electric
- Model: 140CPU11303
- Series: Modicon Quantum
- Processor Type: 80186
- Clock Frequency: 20 MHz
- Memory: 368 kB internal RAM
- Battery Type: Lithium (7 µA to 210 µA)
- Battery Life: 10 years
- Communication Ports: 1 Modbus RS232, 1 Modbus Plus
- Watchdog Timer: 250 ms
- Clock Drift: +/- 8 s/day (0…60 °C)
- I/O Words: 30 I/32 O (distributed), 64 I/64 O (local), 500 I/500 O (network)
- Operating Temperature: 0 to 60 °C (32 to 140 °F)
- Storage Temperature: -40 to 85 °C (-40 to 185 °F)
- Humidity: 95% without condensation
- Ambient Altitude: Up to 5000 m (16404.2 ft)
- Compliance: CE, FM Class 1 Division 2, cUL
- Net Weight: 0.7 lb (0.3 kg)
- Package Dimensions (PCE): 2.0 x 6.5 x 12.2 inches (5 cm x 16.5 cm x 31 cm)
