140CPU67861 Schneider | Quantum Unity Hot Standby Processor

Description

Schneider Electric 140CPU67861: Fault-Tolerant Hot Standby Processor

Mission-Critical Redundancy

The Modicon Quantum 140CPU67861 Unity Processor delivers continuous operation with hot standby capability. Features 266 MHz processing and expandable memory for high-availability systems. New in factory packaging.

Core Specifications

Technical Specifications

• Brand: Schneider Electric
• Model: 140CPU67861
• Redundancy: Hot Standby operation
• Task Management: 1 periodic fast task
• Connectivity:
  • 1x Modbus Plus
  • 1x Modbus
  • 1x USB
• Environmental Protection: Humiseal 1A33 conformal coating
• Certifications: UL, CE, CSA, GOST, Marine

System Architecture

• Rack Support: 2 local racks
• Slot Capacity: 10 slots per rack
• Memory Expansion: PCMCIA card slot
• Diagnostics: Ethernet activity/collision LEDs

Installation Guide

Allocate 2760 mA bus current. Maintain minimum 50mm clearance for ventilation. Use anti-static precautions. Ground chassis properly.

Compatibility

Works with Modicon Quantum HSBY systems. Compatible with Unity Pro software. Supports remote I/O up to 31,744 points.

Package Contents

• 1x Hot Standby processor module

Package Dimensions: 12.8″ x 7.3″ x 4.3″ (32.5×18.5×11 cm)
Weight: 3.14 lb (1.42 kg)

Warranty & Shipping

12-month manufacturer warranty. Ships via FedEx, UPS, DHL in protective packaging. Tracking included.

Industrial Applications

• Power plant control systems
• Offshore platform safety systems
• Continuous process manufacturing
• Marine vessel automation

FAQ

Q: Failover time during switchover?
A: Seamless transition in milliseconds (near-zero downtime)

Q: Marine certification details?
A> Meets DNV-GL, ABS, and Lloyd’s Register standards

Q: Maximum PCMCIA card size?
A> Supports up to 8MB industrial-grade flash cards

Q: Operating temperature range?
A> -40°C to +70°C with conformal coating protection
