Schneider Electric 140DAI54000 Discrete Input Module
The 140DAI54000 is a 16-channel AC input module for Modicon Quantum. It reads 115V AC signals from switches and sensors. This 140DAI54000 module is perfect for industrial control systems.
Main Features
- 16 input channels for 115V AC signals
- Works with Concept, ProWORX 32, and Unity Pro software
- LED indicators for each channel status
- FM Class 1 Division 2 safety certification
- Easy installation in standard Quantum racks
Technical Details
Brand: Schneider Electric
Model: 140DAI54000
Type: Discrete Input Module
Channels: 16 inputs
Voltage: 115V AC
Frequency: 47-63 Hz
Power Use: 5.5W maximum
Bus Current: 180 mA
Isolation: 1780 Vrms between channels and bus
Response Time: 0.75-12.3 ms
Temperature Range: 0°C to 60°C
Weight: 0.31 kg
Simple Installation
Mount in Quantum backplane. Connect 115V AC signals. Green LEDs show input status.
FAQ – Common Questions
What software works with this module?
Works with Concept, ProWORX 32, and Unity Pro software.
How many input channels are there?
16 discrete input channels for AC signals.
What is the input voltage range?
Operates with 115V AC input signals.
What safety standards does it meet?
FM Class 1 Division 2 and UL 508 standards.
What is the response time?
Response time between 0.75 and 12.3 milliseconds.
Shipping & Protection
Fast delivery via FedEx, UPS, DHL. Comes with 12-month warranty coverage.
Technical ? Product ? via WhatsApp: +86 158 8020 0923
Get Installation Guide
Download complete manual here:
Download Modicon Quantum Manual (PDF)
