Description
Schneider Electric 140DAM59000 Mixed I/O Module
The 140DAM59000 combines inputs and outputs in one module. It has 16 AC inputs and 8 solid-state outputs. The 140DAM59000 saves space in your Modicon Quantum system.
Key Features
- 16 inputs for 115V AC signals
- 8 solid-state outputs for 115V AC loads
- Built-in fuse protection for safety
- LED status indicators for all points
- FM Class 1 Division 2 certified
Technical Specifications
Brand: Schneider Electric
Model: 140DAM59000
Type: Mixed Discrete I/O Module
Inputs: 16 channels (115V AC)
Outputs: 8 channels (solid state)
Input Voltage: 115V AC
Output Voltage: 115V AC
Max Load Current: 4A per point, 8A per group
Response Time: 0.5 ms (outputs)
Power Dissipation: 5.5W + load current
Isolation: 1000Vrms between groups
Operating Temp: 0°C to 60°C
Weight: 0.45 kg
Easy Installation
Mount in Quantum backplane. Connect input and output wiring. LED lights show status.
FAQ – Common Questions
What type of outputs does it have?
8 solid-state outputs for AC loads.
How are the channels grouped?
Inputs in 2 groups of 8, outputs in 2 groups of 4.
What is the maximum load current?
4 amps per point, 8 amps per group.
What protection is included?
Internal 5A fuses and RC filter protection.
What external power is needed?
85-132V AC for output circuit operation.
Shipping & Warranty
Fast delivery via FedEx, UPS, DHL. Includes 12-month warranty.
Need ? Have an ? us on WhatsApp: +86 158 8020 0923.
Download Manual
Get complete installation instructions:
Download Modicon Quantum Manual (PDF)
