Schneider Electric 140DVO85300 DC Output Module
The 140DVO85300 delivers high-density control for Modicon Quantum systems. This module provides 32 discrete DC outputs in a compact design. It handles various industrial applications with reliable performance. Get complete installation details from our manual: Download Product Manual.
Electrical Specifications
- Brand: Schneider Electric
- Model: 140DVO85300
- Output Channels: 32 points grouped as 4 sections of 8
- Output Type: Sink logic (negative logic) for standard compatibility
- Voltage Range: 10-30V DC for flexible power supply options
- Current Rating: 0.5A per point, 4A per group, 16A total module
- Surge Capacity: Handles 2.5A for 1ms during startup loads
Performance Features
- Response Time: 2ms maximum switching speed
- Voltage Drop: Less than 0.4V at 0.5A for efficient operation
- Protection: Short-circuit and overvoltage protection on all outputs
- Fusing: Internal 5A fuse protects each group of 8 outputs
- Status Indicators: 32 green LEDs show individual output status
- Fault Detection: Monitors for blown fuses and power loss
System Integration
- Addressing Needs: Requires 2 input words and 2 output words
- Power Consumption: 500 mA from Quantum baseplate
- Heat Management: 2.5W base plus load-dependent dissipation
- Environmental Rating: Operates from 0°C to 60°C (32°F to 140°F)
- Safety Standards: UL 508, CSA 22.2 No 142 certified
- EMC Compliance: 4kV contact/8kV air ESD protection
For technical Support or product Inquiry, Contact: +86 158 8020 0923 via WhatsApp.
Packaging & Delivery
- Package Type: Individual unit packaging (PCE)
- Dimensions: 12.28″ × 6.42″ × 1.77″ (31.2 × 16.3 × 4.5 cm)
- Weight: 15.9 ounces (452 grams) shipping weight
- Shipping: FedEx, UPS, and DHL express services available
- Warranty: 12-month quality guarantee included
- Origin: Manufactured in the United States
Technical FAQ
- How are the 32 outputs organized?
The outputs divide into 4 independent groups of 8 points each with separate fusing. - What is the maximum tungsten load capacity?
It supports 6W at 24V, 3W at 12V, and 2.5W at 10V for lamp loads. - Can this module drive inductive loads?
Yes, with inductance calculated as 0.5/(current² × frequency) for 0.5-4Hz switching. - What happens during a short circuit?
The internal 5A group fuse protects the module from damage. - How is module status monitored?
Green Active LED shows communication, red F LED indicates faults.
