Allen-Bradley 1734-IE2V: 2-Channel Voltage Analog Input Module
The Allen-Bradley 1734-IE2V from Rockwell Automation is a compact POINT I/O analog input module. It offers two voltage input channels for precise process monitoring in industrial applications. Download the complete installation and configuration guide here.
Technical Specifications
- Brand & Manufacturer: Allen-Bradley / Rockwell Automation
- Model: 1734-IE2V
- Series: POINT I/O
- Module Type: Analog Voltage Input
- Number of Channels: 2 single-ended non-isolated inputs
- Input Ranges: 0-10V or ±10V user configurable
- Resolution: 16-bit signed integer (-32,768 to +32,767)
- Absolute Accuracy: ±0.1% of full scale @ 25°C (77°F)
- Conversion Type: Delta Sigma
- Power Dissipation: 0.75 Watts at 28.8V DC
- Thermal Dissipation: 2.5 BTU/hour at 28.8V DC
- Operating Voltage: 12-24V DC
- Data Format: 6 bytes (channel data and status)
- Response Time: Configurable (slow, medium, fast)
- Enclosure Rating: Open-type (IP20 equivalent)
- Operating Temperature: -20°C to 60°C (-4°F to 140°F)
Frequently Asked Questions
- What process variables can the 1734-IE2V monitor?
The module can measure flow, level, pressure, temperature, vibration and other variables. - Can I use both input ranges simultaneously?
No, both channels must use the same voltage range configuration. - What does the signed integer data format mean?
Negative values represent negative voltages in ±10V range mode. - How do I interpret the status indicator lights?
Steady green indicates normal operation, flashing red indicates faults. - Is signal isolation provided between channels?
No, the channels are non-isolated and share a common reference.
