Description
Allen Bradley 1734-IE8CK: 8-Channel Current Input Module
The Allen Bradley 1734-IE8CK from Rockwell Automation is a high-density POINT I/O current input module. It delivers eight precise current input channels with protective conformal coating for industrial environments. Access the complete installation and configuration guide here.
Technical Specifications
- Brand & Manufacturer: Allen Bradley / Rockwell Automation
- Model: 1734-IE8CK
- Series: POINT I/O 1734
- Module Type: High-Density Current Input
- Number of Inputs: 8 single-ended non-isolated channels
- Input Ranges: 0-20 mA, 4-20 mA user selectable
- Absolute Accuracy: ±0.1% full scale @ 25°C (77°F)
- Resolution: 16-bit (0-21 mA range)
- Input Impedance: 60 Ohms
- Conversion Technology: Delta Sigma
- Data Format: Signed integer
- Overload Protection: 28.8V DC maximum
- Conformal Coating: Yes (environmental protection)
- Operating Temperature: -20°C to 60°C (-4°F to 140°F)
- Update Rate: 10 ms per channel (typical)
Packaging Contents
- One 1734-IE8CK current input module
- Installation documentation and quick start guide
- Express shipping via FedEx, UPS, or DHL available
- All products include 12-month performance warranty
Frequently Asked Questions
- What applications suit the 1734-IE8CK best?
Process monitoring, level sensing, pressure measurement and flow control systems. - Does the conformal coating affect heat dissipation?
No, the coating is thin and designed to maintain proper thermal performance. - Can I use different input ranges on each channel?
All channels must use the same current range configuration simultaneously. - What is the typical update rate for all eight channels?
Approximately 80 milliseconds for scanning all eight inputs. - Is external signal conditioning required?
No, the module includes built-in signal conditioning for current inputs.
