Allen-Bradley 1769-OF4CI Isolated Analog Output Module
The 1769-OF4CI is a premium 4-channel isolated current output module. It provides superior noise immunity and precise control. Perfect for critical applications requiring isolated analog signals.
Technical Specifications
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 1769-OF4CI Compact I/O
- Module Type: Isolated Analog Output
- Number of Channels: 4 isolated channels
- Current Outputs: 0-20mA, 4-20mA
- Resolution: 16-bit
- Isolation: Channel-to-channel and channel-to-backplane
- Conversion Rate: 110 ms
- Power Consumption: 2.0 Watts
- Operating Temperature: 0 to 60 °C (32 to 140 °F)
- Backplane Current: 165 mA @ 5V DC
- Accuracy: ±0.35%
- Load Resistance: 0-500 Ω
- Wire Size: 22-14 AWG (Solid), 22-16 AWG (Stranded)
- Weight: 0.27 kg (0.60 lbs)
Installation Guide
Install the 1769-OF4CI within 8 modules of power supply. Use recommended Belden 8761 shielded cable. Handle with care to avoid electrostatic discharge. Mount on DIN rail or panel.
Compare With Other Products
See how the 1769-OF4CI compares to other modules:
Frequently Asked Questions
- Q1: What does “CI” stand for in OF4CI?
A1: It indicates “Current Isolated” output channels. - Q2: Are the channels truly isolated?
A2: Yes, each channel has individual isolation from others and backplane. - Q3: What cable is recommended?
A3: Belden 8761 shielded cable for best performance. - Q4: Does it need field calibration?
A4: No, it auto-calibrates on every power cycle. - Q5: What is the maximum load resistance?
A5: 500 Ω maximum load resistance per channel.
