Description
Allen-Bradley 1769-OG16 TTL Output Module
The 1769-OG16 is a 16-channel TTL output module for precision digital control. It operates at 5V DC levels, making it ideal for interfacing with logic circuits and low-voltage devices.
Technical Specifications
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 1769-OG16 CompactLogix
- Module Type: TTL Digital Output
- Number of Outputs: 16 channels
- Operating Voltage: 4.5-5.5V DC
- On-State Voltage: 0-0.4V DC (guaranteed)
- Off-State Voltage: 4.5-5.5V DC (guaranteed)
- Current per Point: 24 mA maximum
- Minimum Load Current: 0.15 mA
- Dimensions: 4.7 x 1.4 x 3.4 inches
- Mounting: DIN rail or panel mount
- Wire Size: 22-14 AWG (Solid), 22-16 AWG (Stranded)
- Cable Length: Maximum 30 feet recommended
Installation Guide
Install the 1769-OG16 in protected indoor environments only. Keep away from dust, moisture, and direct sunlight. Use cables no longer than 30 feet. Connect maximum 2 wires per terminal.
Compare With Other Products
See how the 1769-OG16 compares to other CompactLogix components:
Frequently Asked Questions
Q1: What does TTL stand for?
A1: Transistor-Transistor Logic – a common digital signal standard.
Q2: What voltage levels does it use?
A2: 0-0.4V for ON state, 4.5-5.5V for OFF state.
Q3: Is this module waterproof?
A3: No, it has an open design and must be installed in protected areas.
Q4: What is the maximum current per output?
A4: 24 milliamps maximum per output point.
Q5: Can I use longer cables than 30 feet?
A5: Not recommended – signal integrity may be affected beyond 30 feet.
