Allen-Bradley 1769-PA2 AC Power Supply
Power your CompactLogix system reliably. The Allen-Bradley 1769-PA2 delivers stable power for your industrial controls. This module is essential for any 1769 series setup.
Why Choose the 1769-PA2?
- Wide Voltage Input: Works from 85V to 265V AC.
- Dual Output Power: Provides 5V DC and 24V DC.
- High Capacity: Supports up to 16 I/O modules.
- Global Certifications: Safe for use in many countries.
Technical Specifications
- Product Line: CompactLogix
- Model Number: 1769-PA2
- Input Frequency: 47-63 Hz
- Output 1: 5V DC @ 2.0 Amps
- Output 2: 24V DC @ 0.8 Amps
- Power Rating: 100VA (120V AC), 130VA (240V AC)
- Inrush Current: Max 25A @ 132V AC
- Fuse Rating: 3.15A Fast-Acting
- Dimensions: 118mm x 70mm x 87mm
- Weight: 1.16 lb (0.53 kg)
- Wire Size: 14-22 AWG Copper
Need help selecting parts? Support & Inquiry: Contact: +86 158 8020 0923 via WhatsApp.
Installation Guide
Mount the 1769-PA2 on a standard DIN rail. Keep 50mm clearance for air flow. Use proper grounding. Connect wires securely.
Compatible Modules
The 1769-PA2 works with many CompactLogix modules. For network connectivity, consider:
1769-ADN DeviceNet Scanner
1769-AENTR Ethernet/IP Adapter
FAQ
- What is the operating temperature? It works up to 60°C (140°F).
- Can I replace the fuse myself? Yes, use a 3.15A fast-blow fuse.
- Is this power supply enclosed? No, it is an open-style module.
- What safety standards does it meet? It has c-UL-us, CE, and C-Tick marks.
- How many modules can it power? It can power 8 modules on each side.
Shipping & Warranty
We ship via FedEx, UPS, DHL. Your order is protected by a 12-month warranty.
