Allen-Bradley 1794-OE4 Flex I/O Analog Output Module
Product Overview
The Allen-Bradley 1794-OE4 is a high-density, four-channel analog output module for the Flex I/O system. It delivers precise control signals to devices like VFDs, control valves, and transducers. Easy to install and configure, it supports both current and voltage outputs without needing calibration.
Technical Specifications
- Brand: Allen-Bradley (Rockwell Automation)
- Model: 1794-OE4
- Output Signals: 0 to 20 mA; 4 to 20 mA; +/- 10VDC; 0 to 10 VDC
- Resolution: 12-bit + sign (Voltage: 2.56mV/cnt, Current: 5.13µA/cnt)
- Accuracy (@25°C): Current: 0.425% FS, Voltage: 0.133% FS
- Conversion Rate: 1.024 ms max (all channels)
- Operating Temperature: 0 to 55 °C (32 to 131 °F)
- Power Supply: 24V DC nominal (10.0 – 31.2V DC range)
- Terminal Bases: 1794-TB2, -TB3, -TB3S, -TB3T, -TB3TS, -TBN
- Keyswitch Position: 4
Installation & Compatibility
- Mounts on standard DIN rail. Requires one compatible terminal base.
- Works with Flex I/O Adapters: 1794-AENT(R), 1794-ACN(R)15, 1794-AND, 1794-ASB, 1794-APB.
- Compatible with MicroLogix controllers for compact solutions.
Packaging & Warranty
- Package Includes: One (1) 1794-OE4 Analog Output Module.
- Warranty: 12 months.
- Shipping: Fast global shipping via FedEx, UPS, and DHL.
Similar Products You May Need
Looking for a digital module? Check out the 1794-IC16 DC I/O Module.
Need analog inputs? See the 1794-IE12 Analog Input Module.
