Description
Bently Nevada Velomitor CT Velocity Transducer: Engineered for Precision
???? Key Highlights
???? Model 190501-01-00-00 | U.S.-Manufactured | Stud Mount (3/8″ 24 Thread)
???? 3.94 mV/mm/s Sensitivity | ±5% Accuracy | MIL-C-5015 Interface
???? No Agency Certifications – Ideal for General Industrial Use
???? Core Specifications for 190501-01-00-00
Frequency Range
3Hz–900Hz (±1dB)
Output Bias
10.1Vdc ±1V
Weight
0.297 kg (10.5 oz)
Operating Temp
-40°C to +85°C
Shock Resistance
5000g Peak
Mounting Torque
4.5 N·m ±0.6
⚡ Performance Features
- ✅ Low Noise: 0.229 mm/s Broadband
- ✅ High Resilience: 316L Stainless Steel Casing
- ✅ Max Cable: 305m (No Signal Loss)
????️ Installation & Compatibility
► Mounting: 3/8″ 24 Thread Stud (Included)
► Connector: MIL-C-5015 (2-Pin)
► Orientation: Any Angle | IP67-Level Protection
???? Package & Support
► Velomitor CT Transducer Unit
► 3/8″ 24 Thread Stud Mount
► COO Available (On Request)
► Warranty: 12 Months | FedEx/DHL/UPS Shipping
