Description
Bently Nevada Trendmaster Pro Accelerometer
Description
Industrial-grade accelerometer for vibration monitoring in tough conditions. Features 316L stainless steel housing and multiple global certifications. Made in USA for reliable machinery health tracking.
Technical Data
- Brand: Bently Nevada
- Model: 200150-07-05
- Series: Trendmaster Pro
- Mounting: 3/8-24 to 3/8 NPT stud
- Approvals: CSA/ATEX/IECEx certified
Key Specifications
| Parameter | Value |
|---|---|
| Measurement Range | ±245 m/s² (±25g) |
| Frequency Range | 10-1000 Hz |
| Output Signal | 10.2 mV/(m/s²) |
| Operating Temp | -40°C to +105°C |
| Shock Resistance | 49,050 m/s² |
Installation Guide
- Apply 2.7-6.8 N•m torque to mounting stud
- Ensure clean, flat mounting surface
- Use 4.7-5.5 Vdc excitation voltage
- Allow 24h cure time after installation
Diagnostics & Maintenance
- Check output bias voltage (+2.5±0.23 Vdc)
- Monitor quiescent current (<800 µA)
- Annual calibration check recommended
Packaging
- 1 × Accelerometer unit
- Mounting hardware
- 12-month warranty
Shipping Options
FedEx | UPS | DHL (select at checkout)
Industry Applications
- Power plant turbine monitoring
- Industrial pump vibration analysis
- Mining equipment health tracking
FAQ
Q: Humidity resistance?
A: 100% RH condensing, non-submerged
Q: Compatible with Trendmaster 2000?
A: Yes, works with both systems
Q: Shock tolerance?
A: Withstands 49,050 m/s² shocks
Q: Material durability?
A: 316L stainless steel housing
Made in USA | COO available on request
