22D-B5P0H204 | Allen Bradley Drive PowerFlex 40P

Description

Allen-Bradley 22D-B5P0H204 PowerFlex Drive – 1HP Compact Motor Control

Small but mighty: The 22D-B5P0H204 delivers precise 1HP (5A) motor control in a space-saving plate-mount design, perfect for tight installations.

Technical Specifications

• Model: 22D-B5P0H204 (Frame B)
• Input: 3-phase 240V AC (208-264V range)
• Output: 5A continuous, 7.5A peak (150%)
• Frequency: 0-500Hz adjustable
• Mounting: Plate mount (IP20)
• Communication: RS-485 + optional DF1 messaging
• Temperature: -10°C to 40°C operating
• Humidity: 5-95% non-condensing

What’s Included

• 22D-B5P0H204 drive unit
• Mounting plate
• Quick start guide

Your Protection

Enjoy 12 months of coverage against manufacturing defects.

Fast Shipping

Reliable delivery via FedEx, UPS or DHL with tracking.

Expert Answers

• Can I use this for a 2HP motor?
  No, maximum is 1HP (5A).
• Is programming software included?
  No, but parameters can be set manually.
• Does it support encoder feedback?
  No, this model uses sensorless vector control.
• Can I mount this outdoors?
  No, IP20 is for indoor use only.
• What’s the restart time after power loss?
  Automatic restart within 2 seconds.

Compare With Higher-Capacity Models

• 22B-E4P2H204 – 3HP waterproof version
• 22B-E6P6C104 – 5HP industrial model
