Description
Allen-Bradley 22D-E4P2N104 PowerFlex Drive – 3HP, 600V, 4.2A
Precision Motor Control for Industrial Systems
The 22D-E4P2N104 delivers reliable speed and torque control for demanding applications. Ideal for PLC systems needing precise motor management.
Technical Specifications
- Model: 22D-E4P2N104 (Suffix: E4=600V, P2=4.2A, N=Panel Mount)
- Power: 3HP (2.2kW) output
- Input: 600V AC 3-phase (414-660V range)
- Control: Sensorless Vector & V/Hz
- Dimensions: 250 × 244 × 94mm
- Weight: 4.1kg (9lbs)
- Temp Range: -10°C to 50°C
- Protection: IP20 enclosure
Key Features
- Removable MOV for surge protection
- Built-in DC brake transistor
- 5 programmable digital inputs
- Dual analog inputs (0-10V/4-20mA)
- RS-485 communication port
Common Questions
- Q: What’s included in warranty?
A: 12-month coverage for defects - Q: How is it shipped?
A: Fast delivery via FedEx, UPS, or DHL - Q: Can it handle power surges?
A: Yes, with built-in MOV protection - Q: What motors work best?
A: 3-phase motors up to 3HP - Q: Is programming difficult?
A: No, includes intuitive HIM interface
Package Contents
- 22D-E4P2N104 drive unit
- Mounting hardware
- Quick start guide
Compare With Similar Models
- 22D-E019H204 (19A, 15HP)
- 22D-E019N104 (19A, 15HP)
