Description
Allen-Bradley 22F-D024N104 PowerFlex 4M VFD – 15 HP, 11 kW
Drive Highlights
- Powerful: 15 HP (11 kW) output for heavy-duty applications
- Flexible Input: 380-480VAC, 3-phase
- Smart Control: Built-in RS485 with multi-drop capability
- Rugged: Works in extreme temps (-40°C to +85°C)
- Easy Setup: Includes removable keypad for quick programming
Key Specifications
- Model: Allen-Bradley 22F-D024N104
- Input: 380-480VAC, 3-phase, 7.5A
- Output: 0-460VAC, 24A, 11kW
- Frame Size: C
- Braking: Integrated dynamic braking resistor
- I/O: 7 digital inputs, 1 analog input (0-10V/0-20mA)
- Mounting: Panel mount (1.9mm min thickness)
- Cooling: Requires 76.2mm top/bottom clearance
Why Customers Choose This Drive
- Zero stacking – Saves panel space
- Surge protection – Removable MOV for safety
- Multi-protocol support – Works with Ethernet/IP, PROFIBUS, more
- Fast delivery – Ships via FedEx/UPS/DHL
Technical FAQs
- What’s the minimum panel thickness for mounting?
1.9mm (0.0747 inches). - Does it work in cold environments?
Yes, operates from -40°C to +85°C. - Can I add a remote keypad?
Yes, supports both integral and remote keypads. - How many drives can connect via RS485?
Supports multi-drop networks (exact number depends on network setup). - Is dynamic braking included?
Yes, has integrated braking resistor.
Warranty & Support
Backed by 12-month warranty. Need wiring diagrams? Download the 22F-D024N104 manual for full technical details.
