24701-16-10-00-083-03-02 Bently Nevada Housing Assemblies

Description

Bently Nevada 24701-16-10-00-083-03-02 Probe Housing Assembly

Complete ready-to-install housing kit for 8mm XL proximity probes. Factory new with full warranty.

Key Features

• For 3300 XL 8mm vibration probes
• Includes 1 meter (39″) cable
• 8.3″ probe penetration depth
• Stainless steel construction
• Complete fitting kit included
• 12 month manufacturer warranty

Part Number Breakdown

24701 - Housing assembly
-16   - 3300 XL 8mm probe
-10   - 1.0m cable length
-00   - No standoff adapter
-083  - 8.3" penetration
-03   - One 3/4-14 NPT plug
        One 3/4-14 to 1/2-14 NPT reducer
        One cable seal grip with grommets for the following
        cable sizes:
        • 1/8 to 3/16 inches
        • 1/4 to 5/16 inches
        • 5/16 to 3/8 inches
-02   - 3/4-14 NPT threads

Industrial Applications

Paper Mill Roller Monitoring

Installed on drying rollers in Ohio paper plant. Handles high humidity and steam exposure.

Offshore Platform Compressors

Used on North Sea gas compressors. Resists saltwater corrosion.

Hydroelectric Turbine Shafts

Monitors shaft vibration in Canadian power dam. Withstands constant moisture.

Technical Specifications

• Material: 303/304 stainless steel
• Weight: 4.1 lbs (1.8 kg)
• Max Dimensions: 29.2″ (74.2 cm)
• Thread Size: 3/4-14 NPT
• Temperature Range: -40°F to 185°F (-40°C to 85°C)
