Description
Product Identity
- Brand Origin
- Bently Nevada
- Manufactured in the U.S.A
- Product Number
- 31000-00-00-00-000-00-00
- Product Category
- Base enclosure without probe components
- Ideal for custom probe system builds
Suffix Structure Breakdown
- Probe Selection
- 00 = Probe not included
- Allows flexible probe choice
- Probe Cable Length
- 00 = Cable not required
- Supports external routing plans
- Standoff Adapter
- 00 = No standoff adapter
- Probe Penetration
- 000 = No probe sleeve
- Fittings Package
- 00 = Supplied without fittings
- Mounting Thread
- 00 = No outer sleeve or retaining nut
- Best for spare or custom assemblies
Material and Construction
- Main Housing Body
- PPS thermoplastic
- Glass reinforced structure
- Conductive fibers for static control
- Sleeve and Retaining Chain
- AISI 304 stainless steel
- High corrosion resistance
- Outer Sleeve and Fasteners
- AISI 303 stainless steel
- Stable mechanical fit
- Sealing Elements
- Neoprene O-ring
- Long service life
Environmental Protection
- Ingress Rating
- IP66 verified
- Resists hose-directed water
- Enclosure Standard
- NEMA Type 4X
- CSA certified
- Hazardous Area Safety
- EN50014 compliant
- Electrostatic discharge controlled
Mechanical Strength Data
- Impact Endurance
- 4 Joules at -39°C
- 4 Joules at 115°C
- 7 Joules at room temperature
- Static Load Capacity
- 912 N supported load
- Tested at 38 mm offset
- Recommended Torque
- 29.4 N·m retaining nut value
Temperature and Physical Data
- Operating Range: -51°C to +105°C
- Weight: 1.2 kg typical
- Surface Stability: Suitable for outdoor use
Pressure and Sealing Notes
- Designed to seal against water only
- Not rated for internal pressure
- Pressure testing not performed before shipment
- Custom pressure tests available on request
Key Selling Points
- Flexible base for custom probe builds
- Strong housing for hazardous locations
- Reduces installation risk
- Supports long-term monitoring systems
- Original manufacturer quality
Warranty and Shipping
- Warranty: 12 months
- Condition: Brand new
- Shipping Options: FedEx, UPS, DHL
Professional FAQ
- Who should choose this zero-configuration housing?
- Users planning custom probe assemblies.
- Is this suitable as a spare enclosure?
- Yes. It is ideal for stock replacement.
- Does this model support future upgrades?
- Yes. Probes and fittings can be added later.
- Is pressure sealing guaranteed?
- No. It is designed for water sealing only.
- What should buyers confirm before ordering?
- Check thread, probe type, and mounting needs.
