31000 Series Proximity Probe Housing Bently Nevada 31000-16-10-00-050-03-02 USA

Description

Quick Product View

• Manufacturer:
  Bently Nevada
• Series:
  31000
• Product Number:
  31000-16-10-00-050-03-02
• Type:
  Proximity Probe Housing

• Made in U.S.A.
• New unit with factory packing.

Model Structure Breakdown

• 31000
  • 16
    • Designed for 3300 XL 8 mm probe.
  • 10
    • Probe cable length 1.0 m.
  • 00
    • No standoff adapter used.
  • 050
    • Probe penetration 5.0 inches.
  • 03
    • NPT fittings and cable seal grip set.
  • 02
    • 3/4-14 NPT mounting thread.

Material and Build Design

• Housing uses glass reinforced PPS.
• Conductive fibers reduce static charge.
• Sleeve and chain made from AISI 304 steel.
• Outer sleeve uses AISI 303 steel.
• Neoprene O-rings ensure tight sealing.

Protection and Durability

• Type 4X rating certified by CSA.
• IP66 protection against dust and water.
• EN50014 compliant for hazardous zones.
• Impact resistance up to 7 Joules.
• Tested at low and high temperatures.

Performance Data

• Operating temperature −51°C to +105°C.
• Recommended tightening torque 29.4 N·m.
• Supports static load up to 912 N.
• Typical unit weight 1.2 kg.

Sealing and Pressure Notes

• Designed to seal differential pressure.
• Internal Viton O-ring inside probe case.
• Not rated for internal pressure testing.
• Hose-directed water sealing supported.

Application Benefits

• Stable probe mounting in harsh areas.
• Protects probe from impact and moisture.
• Improves long-term system reliability.
• Easy access during maintenance.

Shipping and Warranty

• Warranty:
  12 months standard warranty.
• Delivery via FedEx, UPS, or DHL.
• Export-safe industrial packaging.

Professional FAQ

• Is this housing suitable for indoor plants?
• Yes, it performs well in clean environments.
• Does this model support long probes?
• It supports probes with 5 inch penetration.
• Why choose no standoff adapter?
• It simplifies installation on thin casings.
• Are cable seals adjustable?
• Yes, multiple grommet sizes are included.
• What should buyers confirm before ordering?
• Check probe type and mounting thread size.
