Bently Nevada 3300 NSv Proximity Probe: Advanced Machinery Monitoring
Product Overview
Brand new Bently Nevada 330903-00-02-05-11-05 proximity probe in factory packaging. Features FluidLoc cable and connector protector for harsh environments. Direct replacement for 3300 RAM systems with 12-month warranty.
Complete Model Breakdown
- Base Model: 330903 (NSv Probe, M8X1 thread)
- -00-: Unthreaded length = 0 mm
- -02-: Case length = 20 mm
- -05-: Cable length = 0.5 meter
- -11-: Mini ClickLoc connector with protector
- -05-: Multiple agency approvals
Key Technical Data
- Brand: Bently Nevada
- Electrical Resistance: 4.0Ω ±0.5Ω
- Frequency Response: 0-10 kHz (±3dB)
- Cable Capacitance: 69.9 pF/m
- Target Size: Min 8.9mm, Rec 13mm
- Output Sensitivity: 7.87 V/mm
- Temp Range: -52°C to +177°C
Installation Specifications
- Optimal gap: 1.0 mm (40 mils)
- Max torque: 0.56 N•m (5 in-lb)
- Cable bend radius: 25.4 mm min
- Thread engagement: 12 mm max
Enhanced Compatibility
Works with all 3300 XL NSv Proximitors. Fully backward compatible with 3300 RAM systems. Superior chemical resistance vs older models.
Packaging & Support
Factory-sealed with protective materials. Includes 12-month manufacturer warranty.
Global Shipping Options
Express delivery via FedEx, UPS, DHL. Ships within 24hrs of order.
Frequently Asked Questions
Q: What’s the purpose of the connector protector?
A: Prevents damage during installation in tight spaces
Q: Can this measure shafts under 8.9mm?
A: Not recommended – accuracy decreases below minimum target size
Q: Difference between 20mm and 50mm case versions?
A: Case length (-02- vs -05-) – choose based on mounting depth
Q: Maximum pressure rating?
A: Not rated – contact engineering for pressure testing
