M8 Thread Vibration Probe with Chemical Protection
Bently Nevada 3300 NSv Probe (330903-00-03-10-11-05) features 30mm case and FluidLoc cable with connector protector. Ideal for chemical environments and small equipment. New with factory warranty.
Product Identification
Complete Part: 330903-00-03-10-11-05
- 330903 : M8 thread without armor
- 00 : 0mm unthreaded section
- 03 : 30mm case length
- 10 : 1.0 meter cable
- 11 : FluidLoc with protector
- 05 : Safety approvals
Key Specifications
- Case Length: 30mm (medium size)
- Resistance: 4.2Ω ±0.5
- Cable Protection: FluidLoc + connector guard
- Frequency Range: 0-10,000 Hz
- Linear Range: 0.25-1.75mm
- Scale Factor: 200 mV/mil
- Max Field Wiring: 305 meters
Model Comparison
| This Model 330903-00-03-10-11-05 | 30mm case FluidLoc + protector Approvals |
| 330903-00-02-10-01-00 | 20mm case Standard cable No approvals |
| 330903-00-02-10-11-00 | 20mm case FluidLoc only No approvals |
Installation Guide
- Torque: 5.1 N•m (45 in•lb)
- Max Torque: 7.3 N•m (65 in•lb)
- Thread Limit: 12mm
- Gap Setting: 1.0mm optimal
- Bend Radius: 25.4mm min
Shipping & Warranty
- FedEx, UPS, DHL options
- 12-month manufacturer coverage
- New in sealed packaging
Technical Questions
Q: Why FluidLoc with protector?
A: Double protection against chemicals and physical damage
Q: Suitable for ATEX zones?
A: Yes, carries multiple safety approvals
Q: Minimum shaft size?
A: Works on 8.9mm shafts but 13mm recommended
Q: Difference between 11 and 12 options?
A: 11 has connector protector, 12 does not
