3300 XL 8 mm Proximity Probe Bently Nevada – 330101-00-14-10-02-00

Description

Overview

The Bently Nevada 3300 XL 8 mm Probe (Product No. 330101-00-14-10-02-00) offers a compact design with a 1.4-inch case length, tailored for space-constrained industrial applications. Featuring a 3/8-24 UNF thread and unarmored construction, it integrates patented TipLoc and CableLoc technologies to ensure secure tip bonding and 75 lbf cable retention.

Technical Specifications

• Brand: Bently Nevada
• Model: 330101-00-14-10-02-00
  • Suffix Breakdown:
    • 00: 0.0″ unthreaded length
    • 14: 1.4″ overall case length
    • 10: 1.0m total length (3.3 ft)
    • 02: Miniature coaxial ClickLoc connector + standard cable
    • 00: No agency approvals required
• Probe Diameter: 8 mm
• Thread Type: 3/8-24 UNF
• Frequency Response: 0.5 Hz to 12 kHz (±3 dB)
• Insulation Resistance: >100 MΩ at 500 VDC
• Vibration Resistance: Withstands 20 g peak (10 Hz to 2 kHz)
• Shock Tolerance: 50 g, 11 ms half-sine pulse
• Ingress Protection (IP) Rating: IP67 (dust/water-resistant)
• Cable Bend Radius: Minimum 25 mm (0.98 in)

Contact Support

For certification documents or custom configurations:
sales@ubestplc.com

Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
