Description
Complete Suffix Breakdown
- 330104-00-03-05-01-00
- 00: 0mm Unthreaded Length
- 03: 3mm Overall Case Length
- 05: 0.5 Meter Total Cable Length
- 01: ClickLoc Connector with Protector
- 00: No Agency Approvals Required
Precision Technical Data for 330104-00-03-05-01-00
- Voltage Input: -17.5Vdc to -26Vdc (±12mA)
- Probe Resistance: 7.45Ω ±0.50 @ 0.5m
- Signal Stability: <2mV/V Power Supply Sensitivity
- Operating Range: +18°C to +27°C (2000m Max Altitude)
- Thread Type: M10×1 with Armor Protection
Industry-Specific Applications
- Chemical processing pump shaft monitoring
- Vibration detection in packaging machinery rollers
- Position control for semiconductor wafer handlers
Enhanced Connection System
- Features dust-proof connector protector
- Sealed with Viton® O-ring (IP67 equivalent)
- Works with 3300 XL 8mm Proximitor® III+ systems
Contact Engineers: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
Recommended Bently Nevada Probes
| 330103-00-05-50-02-05 | 330103-00-12-50-02-CN | 330103-00-11-90-02-CN |
|---|---|---|
| 330103-00-05-90-02-05 | 330103-00-03-90-02-00 | 330103-00-03-90-12-CN |
| 330103-00-07-20-02-00 | 330103-00-03-20-02-00 | 330103-00-13-20-12-CN |
