Description
Product Overview
The Bently Nevada 3300 XL 8 mm Probe (Model 330140-08-30-12-00) is engineered for reliability in fluid-intensive industrial environments. Featuring a 3.0-meter FluidLoc cable and a miniature ClickLoc connector, this probe prevents oil and liquid ingress, ensuring uninterrupted performance. Its 8 mm PPS plastic tip and stainless steel casing deliver rugged durability, while the patented TipLoc and CableLoc designs provide 330 N (75 lbf) pull strength.
Technical Specifications
- Brand: Bently Nevada
- Model: 330140-08-30-12-00
- Suffix Breakdown:
- 08: 0.8-inch case length
- 30: 3.0-meter cable (9.8 feet)
- 12: ClickLoc connector + FluidLoc cable
- 00: No agency certifications required
- Suffix Breakdown:
- Probe Tip: Polyphenylene sulfide (PPS)
- Case Material: AISI 303/304 stainless steel
- DC Resistance: 8.17 Ω ±0.50 (3.0-meter length)
- Scale Factor: 7.87 V/mm ±5% (1/5m systems) or ±6.5% (9m/ETR systems)
- Linearity Deviation: <±0.025 mm (1 mil) for 1/5m; <±0.038 mm (1.5 mil) for 9m/ETR
- Humidity Resistance: <3% ASF change at 93% humidity (56 days, IEC 68-2-3)
- Fluid Resistance: IP68-rated FluidLoc cable for submersion up to 1.5 meters
- Signal Bandwidth: 0.5 Hz to 12 kHz for precise dynamic measurements
- Cable Flexibility: 40,000+ bend cycles at 20 mm radius
Contact Information
For inquiries or custom configurations, email sales@ubestplc.com. Our team will gladly assist with technical details or order processing.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
