Description
Product Overview: Premium Vibration Probe
Introducing the Bently Nevada 330140-08-10-02-00 proximity probe. This heavy-duty 8 mm sensor delivers precise machine health data. It features patented TipLoc and CableLoc technology for maximum durability. Ideal for critical industrial machinery protection.
Complete Technical Specifications
- Core Identification
- Brand: Bently Nevada
- Model & Series: 330140-08-10-02-00 (3300 XL)
- Product Type: 8 mm Proximity Probe with Armor
- Key Performance Data
- Measurement Range: Linear over 2.03 mm (80 mils)
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil) ±5%
- Linearity (DSL): Better than ±0.025 mm (±1 mil)
- Probe Resistance: 7.59 Ω ±0.50 Ω (for 1.0m length)
- Physical & Environmental Specs
- Temperature Range: -52°C to +177°C (-62°F to +350°F)
- Case Material: AISI 303/304 Stainless Steel
- Tip Material: Rugged Molded PPS Plastic
- Seal: Viton® O-ring for pressure differential
- Cable Pull Strength: 330 N (75 lbf) with CableLoc
- Humidity Resistance: Less than 3% ASF change at 93% RH
- Configuration Details
- Overall Length: 0.8 inch (Case) + 1.0 meter Cable
- Connector: Miniature Coaxial ClickLoc
- Agency Approval: Standard (Not Required)
Simple Installation & Setup
This probe integrates easily with Bently Nevada 3300 XL monitors. The ClickLoc connector enables tool-free, secure attachment. The robust 8 mm body withstands physical stress during installation.
Easy Maintenance & Diagnostics
Minimal maintenance is required. Monitor the probe gap voltage for health checks. The design allows for straightforward calibration and replacement if needed.
Compatibility Notes
Directly compatible with 3300 XL monitoring systems. Verify system requirements with your monitor manual. Not recommended for use with incompatible systems.
Certification & Package
- Compliance: Manufactured to Bently Nevada specifications.
- Package Includes: One 8 mm Probe, 1.0m Cable, ClickLoc Connector.
- Warranty: Full 12-Month warranty against defects.
- Global Shipping: Fast delivery via FedEx, UPS, or DHL.
Typical Applications
Perfect for measuring vibration and position on turbines, compressors, pumps, and large motors. Essential for predictive maintenance programs to detect unbalance, misalignment, and bearing wear.
Frequently Asked Questions
Why choose an 8 mm probe over a 5 mm?
The 8 mm probe offers superior physical strength. Its thicker body resists damage in harsh plant environments much better.
Is this the right probe for my existing monitor?
This 3300 XL probe works with 3300 series monitors. Check your monitor’s model number to confirm compatibility.
What’s the first sign of a probe problem?
A drifting or unstable gap voltage reading is a common early warning. A quick resistance check can confirm probe health.
Can it handle wet or oily conditions?
The standard probe seals against pressure differential. For fluid ingress along the cable, inquire about the optional FluidLoc version.
How durable is the cable connection?
Very durable. The patented CableLoc design provides 75 pounds of pull-off strength, preventing cable separation.
