Description
Certified Vibration Probe for Tough Environments
The Bently Nevada 330101-00-59-15-12-05 is a premium industrial sensor. It features special FluidLoc cable. This probe works safely in hazardous areas. It is ideal for oil, gas, and chemical plants. Made in the USA for reliability.
Model Configuration Breakdown
- Base Code 330101: 3300 XL 8mm Probe, 3/8-24 UNF thread, no armor
- First Option 00: Unthreaded Length = 0.0 inch
- Second Option 59: Case Length = 5.9 inches
- Third Option 15: Cable Length = 1.5 meters (4.9 feet)
- Fourth Option 12: ClickLoc connector with FluidLoc cable
- Fifth Option 05: Approved for CSA, ATEX, and IECEx standards
Top Product Advantages
- Hazardous Area Certified: Safe for use in explosive atmospheres.
- FluidLock Technology: Prevents oil migration through the cable.
- Extended Reach: 1.5m cable offers flexible installation.
- Superior Durability: Patented TipLoc and CableLoc for strength.
- Wide Temp Range: Operates from -52°C to +177°C.
Full Technical Parameters
- Probe Type: 3300 XL 8mm Proximity Probe
- Measurement Range: 2.0 mm (80 mils) linear
- Gap Setting (Radial): -9 Vdc (~1.27 mm / 50 mils)
- Sensitivity (ISF): 7.87 V/mm (200 mV/mil)
- Linearity Error (DSL): Less than ±0.025 mm (±1 mil)
- Probe Resistance (1.5m): 7.73 Ω ± 0.50
- Cable Capacitance: 69.9 pF per meter typical
- Max Field Wiring: 305 meters (1000 feet)
- Case Material: AISI 303/304 Stainless Steel
- Tip Material: PPS Plastic
- Seal: Viton O-ring
- Humidity Stability: Less than 3% change at 93% RH
- Cable Pull Strength: 330 N (75 lbf)
- Approvals: CSA, ATEX, IECEx
Installation & Care Instructions
- Keep installation temperature above -34°C to protect the seal.
- Use the -9 Vdc gap setting for standard radial vibration.
- The FluidLoc cable is designed for wet, oily conditions.
- Follow hazardous area wiring codes for your region.
Support & Logistics
- This product is covered by a 12-month warranty.
- Fast global delivery via FedEx, UPS, and DHL couriers.
- Complete documentation and certificates included.
Expert Questions & Answers
About Certifications
- What do the CSA, ATEX, IECEx approvals mean?
- They certify this probe for use in potentially explosive atmospheres in North America, Europe, and internationally.
- Can I use this in a Zone 1 hazardous area?
- Yes, when installed correctly per the relevant safety drawings and standards.
Technical & Application
- Why is the cable length 1.5 meters?
- It provides extra reach for installations where the sensor is not close to the measurement point.
- What is the advantage of FluidLoc over standard cable?
- It seals the cable core, preventing machine oil from leaking out along the cable path.
Purchasing Guidance
- My application is not hazardous. Do I need this model?
- If you don’t need the safety certifications, you can choose a standard approval model to save cost.
