Description
Bently Nevada 3300 XL Proximity Sensor
Model ID
330103-00-04-10-01-05
▸ M10x1 Thread
▸ Armor-Free
▸ 40mm Case
Protected Connector Edition
Features ClickLoc connector with protective sleeve for enhanced durability in high-vibration environments. Triple-certified for explosive atmospheres with extended temperature resilience.
Technical Profile
- ◼︎ DC Resistance: 7.59Ω ±0.50 @1m
- ◼︎ Sensing Range: 0.25-2.3mm
- ◼︎ Output Curve: -1 to -17V linear
- ◼︎ Weight Density: 323g/m
Environmental Rating
????️ Temp Range
-52°C to +177°C
???? Humidity
93% RH Stable
Certification Badges
✔️ ATEX Zone 0
✔️ IECEx EPL Ga
✔️ CSA Class I Div1
Industrial Implementations
????️ Construction
Concrete mixer bearing monitoring
⚗️ Chemical
Reactor agitator shaft alignment
???? Transportation
High-speed train axle monitoring
???? Includes connector protector & installation guide
12-month performance warranty | Contact Engineering Team
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
Recommended Bently Nevada Probes
| 330103-00-03-10-01-00 | 330103-00-09-10-02-00 | 330103-10-20-10-02-00 |
|---|---|---|
| 330103-00-20-10-02-00 | 330103-00-15-10-02-00 | 330103-00-11-10-02-05 |
| 330103-00-10-10-02-05 | 330103-00-03-10-02-05 | 330103-00-07-10-01-05 |
