330103-00-04-50-12-CN Proximity Probe Without Armor – Bently Nevada

Description

Bently Nevada 3300 XL 8 mm Proximity Probe (Product No. 330103-00-04-50-12-CN)

330103-00-04-50-12-CN: A rugged 5-meter industrial proximity probe with FluidLoc™ cable for oil-immersed environments. Features M10x1 threading and PPS corrosion-resistant tip, engineered for long-range vibration monitoring in hazardous areas.

Technical Specifications

• Brand: Bently Nevada
• Model: 3300 XL 8 mm Proximity Probe
• Suffix Code Breakdown:
  • Unthreaded Length: 00 (0 mm)
  • Case Length: 04 (40 mm)
  • Cable Length: 50 (5.0 meters)
  • Connector: 12 (FluidLoc™ ClickLoc)
  • Certification: CN (Country-Specific)
• Electrical Characteristics:
  • DC Resistance: 8.73Ω ±0.5Ω @5m
  • Output Voltage Range: -1 to -17 Vdc
  • Linear Detection Range: 0.25–2.3 mm (10–90 mils)
• Mechanical Properties:
  • Thread Engagement Limit: 15 mm
  • Cable Weight: 323 g/m (11.4 oz/ft)
  • Pressure Seal: Viton® O-ring (Untested by default)
• Environmental Ratings:
  • Operating Temp: -52°C to +177°C (Probe Tip)
  • Cable/Connector Temp: -51°C to +260°C
  • Humidity Stability: ±3% ASF @93% RH (56 days)

Installation Requirements

• Compatible Proximitor: 5-meter sensor variant only
• Wiring Specification: 3-conductor shielded triad (16–24 AWG)
• Max System Cable Run: 305 meters (1000 ft)

Certifications & Safety

• ATEX/IECEx: AEx/Ex ia IIC T1-T5 Ga (Zone 0)
• UL/CEC: Class I Div 2 Groups A-D
• Marine Grade: IEC 68-2-3 salt fog certified

Packaging & Support

• Included Components:
  • Probe assembly with FluidLoc™ cable
  • ClickLoc connector kit
• Warranty: 1-year performance guarantee

Industrial Applications

• Hydroelectric Turbines: Shaft runout monitoring in high-moisture environments
• Offshore Drilling Rigs: Bearing health analysis with FluidLoc™ corrosion protection
• Chemical Processing: Seal-less pump vibration tracking in ATEX Zone 0 areas

Pressure Testing Services Available: sales@ubestplc.com
