Description
Bently Nevada 3300 XL 8 mm Proximity Probe
Premium non-contact vibration monitoring solution for industrial machinery. 330103-00-05-10-02-CN designed with 8 mm PPS tip and stainless steel case for reliable gap measurement in harsh environments.
Key Technical Data
- Brand: Bently Nevada
- Model: 3300 XL 8mm Proximity Probe (330103-00–05–10–02–CN)
- Range: 0.25-2.3mm (10-90 mils)
- Accuracy: ±0.50Ω DC resistance tolerance
- Output: -1 to -17V DC linear signal
- Temp Range: -52°C to +218°C (Tip), -51°C to +260°C (Cable)
- Cable: 1.0m standard with ClickLoc connector
- Pressure Seal: Viton® O-ring (15mm thread engagement)
Installation & Compatibility
M10x1 threaded mounting, recommended gap setting -9V DC (1.27mm). Compatible with 3300 XL Proximitor Sensors and monitors up to 305m distance. Shielded triad cable required for EMI protection.
Certifications
- ATEX/IECEx: AEx/Ex ia IIC T1-T5 (Zone 0)
- Class I Div 2, Groups A-D
- IEC 68-2-3 humidity certified
Package Includes
- Probe assembly (323g/m weight)
- 3m standard cable
- Mounting hardware
Industrial Applications
Used in gas turbine monitoring, pump bearing vibration analysis, and compressor shaft displacement measurement. Trusted by power generation and oil & gas operators worldwide.
Contact: sales@ubestplc.com for technical specifications or custom pressure testing requests.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
