Description
Bently Nevada 3300 XL 8 mm Proximity Probe
A high-performance proximity probe (330103-00-06-10-02-CN) designed for precise vibration and position monitoring in industrial machinery. Features a robust stainless steel case, Viton® O-ring seal, and compatibility with hazardous environments.
Technical Data
- Brand: Bently Nevada
- Model: 3300 XL 8 mm Proximity Probe
- 330103-00-06-10-02-CN Suffix: 00-06-10-02-CN (Unthreaded Length: 00mm; Case Length: 60mm; Cable: 1.0m; Connector: ClickLoc; Certification: Country-Specific)
- Linear Range: 0.25–2.3 mm (10–90 mils), Output: -1 to -17 Vdc
- Accuracy: Probe Resistance: 7.59Ω ±0.50
- Temperature Range: -52°C to +177°C (Standard); Extended Tip: +218°C, Cable: +260°C
- Materials: PPS Tip, AISI 303/304 SST Case
Installation & Compatibility
- Thread: M10x1 (Max Engagement: 15mm)
- Cable: 0.2–1.5 mm² (16–24 AWG), Shielded Triad, Up to 305m
- Compatible with intrinsically safe (ia) and non-incendive (nA/ec) systems
Certifications
- ATEX/IECEx: AEx/Ex ia IIC T5-T1 Ga, AEx/Ex nA/ec llC T5-T1 Gc
- Class I, II, III; Groups A–G; Zones 0/2
Package & Warranty
- Includes: Probe, Documentation, Viton® O-ring
- Warranty: 1-Year Limited
Applications
Ideal for monitoring radial vibration in gas turbines, compressors, pumps, and rotating machinery requiring hazardous area compliance.
Contact Us: For inquiries, email sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
