330103-00-11-50-02-00 | ATEX-Certified Industrial Vibration Sensor M10 Thread

Description

Bently Nevada 3300 XL Extended-Range Proximity Probe

Model: 330103-00-11-50-02-00

| Core Configuration |

• Manufacturer: Bently Nevada
• Suffix Map for 330103-00-11-50-02-00:
  • 00: 0mm Unthreaded Design
  • 11: 110mm Heavy-Duty Case
  • 50: 5.0m Industrial Cable (16.4 ft)
  • 02: ClickLoc Connector (Standard Triad)
  • 00: No Certification Required

| Performance Excellence |

• Electrical: 8.73Ω ±0.50 @5.0m (5m Proximitor Exclusive)
• Frequency Response: 0.5–12 kHz (±1.5dB)
• Shock Survival: 100g Peak (6ms Half-Sine Pulse)
• Cable Rating: 300V AC/DC Insulation Strength

| Environmental Mastery |

• Seal System: Viton® O-Ring (Optional 30bar Hydrostatic Test)
• Temp Resilience:
  • Probe: -52°C to +218°C
  • Cable: -51°C to +260°C (Oil-Resistant Jacket)
• Chemical Resistance: Withstands pH 1–14 Exposure

| Compliance & Validation |

• IEC 60079-0:2017 (Explosive Atmospheres)
• CE EMC Directive 2014/30/EU

| Industrial Pioneering |

• Cryogenic Systems: Turboexpander Monitoring in LNG Liquefaction Plants
• Pharmaceuticals: Sterile Vessel Monitoring for Vaccine Production Lines
• Waste Management: Shredder Bearing Analysis in Municipal Waste Facilities

| Support Ecosystem |

• Package: Probe, 5.0m Cable, Technical Datasheet
• Warranty: 12 Months (Non-Corrosive Environments)
• Contact: sales@ubestplc.com for Cryogenic Application Guides

Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
