Description
Product Description
The Bently Nevada 330104-00-12-05-02-00 is a high-performance 3300 XL 8 mm Proximity Probe designed for precise vibration and position monitoring. Built with AISI 303/304 stainless steel and a PPS probe tip, it ensures durability in industrial environments. Features include a Miniature ClickLoc connector, 0.5-meter cable, and Viton® O-ring sealing for pressure resistance.
Technical Data
- Brand: Bently Nevada
- Model: 3300 XL 8 mm Proximity Probe
- Full Suffix: 330104-00-12-05-02-00
- Range: 1.27 mm (50 mils) gap
- Accuracy: 7.45 ±0.50 Ω DC resistance
- Output: -24 Vdc, 50 Ω resistance
- Temperature: +18°C to +27°C (+64°F to +80°F)
- Thread: M10 x1
- Cable: Armored, 0.5 m (1.6 ft)
Installation & Compatibility
Works with 3300 XL 8 mm Proximitor Sensors. Requires M10 threading. Compatible with AISI 4140 steel targets. Use -17.5 Vdc to -26 Vdc power for optimal performance.
Certifications
Agency Approval: Not required (Option 00).
Package Includes
- 1x 8 mm Proximity Probe
- Miniature ClickLoc Connector
- Installation Manual
Warranty
1-year limited warranty against manufacturing defects.
Applications
Ideal for gas turbines, pumps, compressors, and rotating machinery requiring vibration monitoring.
Contact
For inquiries: sales@ubestplc.com
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
