330105-02-12-15-02-00 Bently Nevada Reverse Mount Probe

Description

Description

The Bently Nevada 330105-02-12-15-02-00 3300 XL 8 mm Probe is a non-certified industrial sensor optimized for general-purpose applications. With a 1.5 m (4.9 ft) cable and Miniature ClickLoc connector, this probe delivers precise measurements in non-hazardous environments. Built with PPS tip and stainless steel housing, it combines reliability with cost-efficiency for standard operating conditions.

Technical Specifications

• Brand/Model: Bently Nevada 330105-02-12-15-02-00
• Suffix Configuration:
  • 15: 1.5 m (4.9 ft) cable length
  • 02: Miniature ClickLoc connector
  • 00: No agency certifications required
• Electrical:
  • DC Resistance: 7.73Ω ±0.50
  • Cable Options: FEP/PFA insulation (0.5-9m)
• Mechanical:
  • Thread: 3/8-24 UNF (14.3 mm max engagement)
  • Tensile Strength: 330N (case) / 270N (connectors)
  • Weight: 323 g/m (11.4 oz)
• Environmental:
  • Temp Range: -52°C to +177°C (Standard)
  • Humidity: <3% ASF drift @ 93% RH (IEC 68-2-3)
