Description
Overview
The Bently Nevada 3300 XL 8 mm Probe (Model 330140-08-20-12-05) delivers enhanced durability and reliability for industrial monitoring applications. Featuring a patented TipLoc molding process and CableLoc design, this probe ensures robust physical integrity with 330 N pull strength. Additionally, the optional FluidLoc cable prevents fluid ingress, making it ideal for harsh environments.
Technical Specifications
- Brand: Bently Nevada
- Model: 330140-08-20-12-05
- Suffix Breakdown:
- 08: 0.8-inch overall case length
- 20: 2.0-meter total cable length
- 12: Miniature coaxial ClickLoc connector with FluidLoc cable
- 05: CSA, ATEX, IECEx certifications
- Suffix Breakdown:
- Probe Tip Material: Polyphenylene sulfide (PPS)
- Case Material: AISI 303/304 stainless steel
- Temperature Range:
- Standard: -62°F to +350°F (-52°C to +177°C)
- Extended: Up to +500°F (+260°C) for cable/connector
- DC Resistance: 7.88 Ω ±0.50 (2.0-meter length)
- Scale Factor: 7.87 V/mm ±5-6.5% (depending on system)
- Weight: 323 g/m (11.4 oz/ft)
- Humidity Resistance: <3% ASF change in 93% humidity (56 days)
Contact Information
For inquiries or custom configurations, email sales@ubestplc.com. Our team will gladly assist with technical details or order processing.
Explore more detailed information in official datasheet here: 3300 XL 8 mm Proximity Transducer System Datasheet
