Description
Bently Nevada 12-Inch Vibration Probe: Heavy-Duty Machinery Monitoring
Essential Features
Professional-grade 5mm vibration sensor with extended 12-inch stainless steel body. Perfect for hard-to-reach equipment monitoring. Made in USA with PPS tip for chemical resistance.
Technical Details
- Full Model: 330171-00-12-05-02-00
- Case Length: 12 inches (304 stainless steel)
- Voltage Range: -17.5 to -26 VDC
- Temperature: -35°C to +177°C operating
- Cable: 0.5m FEP triaxial (25.4mm min bend)
- Thread: 1/4-28 UNF (max 0.375″ engagement)
- Resistance: 7.45Ω ±0.50 (center to outer conductor)
Real-World Applications
- Steam Turbines: Detected bearing wear at 4,500 RPM in power plant
- Pipeline Compressors: Prevented seal failure in -20°C Arctic operations
- Water Pumps: Measured 0.003″ shaft deflection in chemical processing
Installation Tips
- Drill with #3 or larger tap for threads
- Torque to 5.1 N·m (45 in-lb) – never exceed 7.3 N·m
- Maintain 1.27mm gap to target surface
Shipping & Support
- 12-month manufacturer warranty
- Global delivery via FedEx/UPS/DHL
- Weight: 0.323 kg (ready for express shipping)
Problem Solvers
- Vibration false alarms?
Our 50Ω output reduces signal noise - High-temp failures?
+177°C rating handles turbine heat - Cable damage?
222N tensile strength resists pull force
Quick Answers
Q: Minimum installation clearance?
A: Requires 12-inch case space plus cable bend radius
Q: Works with 3300 XL system?
A: Yes – compatible with all Bently Nevada 3300 monitors
Q: Chemical resistance?
A: PPS tip withstands oils, solvents and acids
Q: Delivery time to Germany?
A: 3 business days via DHL Express
