330191-00-70-15-05 Bently Nevada – Proximity Probes 3300 XL 8 mm ETR Probe

Description

High-Torque Industrial Monitor

Bently Nevada 3300 XL (P/N: 330191-00-70-15-05) – 7″ heavy-duty probe with 1.5m cable. ATEX/IECEx/CSA certified. Operates at -55°C to +232°C. 1-year warranty.

???? Key Mechanical Specs for 330191-00-70-15-05

| Feature          | Specification          |
|-------------------|-------------------------|
| Thread Type       | 3/8-24 UNF              |
| Case Length       | 7 inches (178mm)       |
| Cable Pull Force  | 330N (75 lbf)           |
| Connector Torque  | 0.565 N·m (5 in-lbf)    |

⚡ Electrical Profile

• Resistance: 7.73Ω ±0.50
• Voltage Range: -17.5V to -26V DC
• Output Impedance: 50Ω
• Insulation: FEP triaxial cable

???? Top 3 Applications

1. ????️ Wind Turbines: Monitors gearbox vibrations in 80m towers
2. ???? Food Processing: Tracks stainless steel mixers in chocolate plants
3. ⛏️ Mining Crushers: Detects bearing wear in underground coal mills

⚠️ Critical Notes

• Max altitude: 2000m above sea level
• Requires 10kΩ load resistor
• Do NOT use with extension cables

???? Certifications

• ATEX II 1G Ex ia IIC T4
• IECEx Ex ia IIC T4
• CSA Class I Div 1 Groups C&D
