330701-00-24-50-01-00 Bently Nevada 3300 XL 11 mm Probe

Description

Bently Nevada 3300 XL 11mm Proximity Probe

Product Description

Industrial vibration sensor for machine monitoring. Made in USA. Works with 5-meter Proximitor sensors. Stainless steel case with PPS tip.

Key Features

• 5-meter cable length for flexible installation
• Works in extreme temperatures (-51°C to +177°C)
• ClickLoc connector for secure connections
• Viton O-ring seal for pressure protection
• Certificate of Origin available

Full Model Information

• Brand: Bently Nevada
• Model: 3300 XL 11mm Probe
• Product No: 330701-00-24-50-01-00
• Suffix Breakdown:
  • 00: 0 in unthreaded length
  • 24: 2.4 in case length
  • 50: 5.0 meter cable
  • 01: Standard cable with ClickLoc
  • 00: No agency approvals

Technical Specifications

• Cable: 5m triaxial (75 Ω)
• Resistance: 7.2Ω ±0.8Ω
• Thread: 1/2-20 UNF
• Max Torque: 15.2 N•m (133 in•lb)
• Bend Radius: 25.4mm min
• Temperature Range: -51°C to +177°C
• Tip Material: PPS plastic
• Case Material: Stainless steel

Installation Notes

• Max thread engagement: 0.75 inch
• Connector torque: Finger tight only
• Do not expose below -34°C before install
• For pressure testing: contact manufacturer

Compatibility

This Bently Nevada 3300 XL model works only with 5-meter Proximitor sensors. Fits 1/2-20 UNF mounts.

Certifications

No agency approvals (Option 00). Made to industrial standards.

Package Includes

• Probe with 5m cable
• ClickLoc connector protector
• 12-month warranty

Shipping Options

FedEx, UPS, or DHL. Ships same day.

FAQ

• Can I use this with 9m systems?
  No, this 5m model is for 5m Proximitor only
• Is pressure testing included?
  No, contact us for pressure testing
• Cable material type?
  FEP-insulated triaxial cable
• Minimum install temperature?
  Do not expose below -34°C (-30°F)
• Thread specifications?
  1/2-20 UNF or M16x1.5 options

Get Full Details

Download complete specs for the Bently Nevada 3300 XL probe:
3300 XL 11 mm Proximity Transducer System Datasheet
