Description
Bently Nevada 9-Meter Proximity Probe – Long-Reach Vibration Sensing
Engineered in USA for demanding industries, this Bently Nevada 3300 XL probe features an extra-long 9-meter cable for flexible installations. Withstands extreme temperatures from -51°C to +177°C.
PRODUCT HIGHLIGHTS
- Long 9m cable (29.5 ft) for distant monitoring
- Protected connector with dust cap
- Industrial-grade PPS tip and stainless steel body
- Viton O-ring for pressure sealing
- Works in harsh factory environments
MODEL DETAILS: 330701-00-24-90-01-00
- 00 : 0.0″ unthreaded length
- 24 : 2.4″ case length
- 90 : 9.0 meter cable
- 01 : ClickLoc connector with protector
- 00 : No agency approval needed
TECH SPECS
- Brand: Bently Nevada
- Type: 3300 XL 11mm Probe
- Cable: 9m triaxial (75Ω)
- Resistance: 8.5Ω ±1.1Ω
- Thread: 1/2-20 UNF
- Max torque: 15.2 N•m
- Weight: 0.17kg
- Temp range: -51°C to +177°C
INSTALLATION NOTES
- Max thread engagement: 19mm (0.75″)
- Hand-tighten connectors only
- Keep above -34°C during install
- Minimum bend radius: 25.4mm
PROFESSIONAL FAQ
- Q: Can this probe get wet?
A: Yes, FEP cable resists fluids - Q: Replacement connector available?
A: Yes, order ClickLoc PN 330800-90-00 - Q: Suitable for food processing?
A: Yes, SST and PPS materials meet standards - Q: Maximum cable pull force?
A: 50N (11.2 lbs) during installation - Q: Calibration needed?
A: Factory-calibrated, no field adjustment
Need setup guidance? Download the Bently Nevada 3300 XL manual: Get Installation PDF
