Description
Bently Nevada 330701-00-50-50-02-CN Industrial Vibration Sentinel
Mission-Critical Specifications
5-inch Deep-Reach Design | China-Certified | High-Temperature Warrior
Advanced Technical Parameters
- Cable Capacitance: 98pF/m ±5% @1kHz
- Phase Consistency: <0.5° deviation across 5m cable
- Vibration Survival: 15g RMS (10-2000Hz)
- Insulation Resistance: >1000MΩ @500VDC
- Dielectric Strength: 1500V AC/1min
Suffix Code Breakdown
330701-00-50-50-02-CN ├── 00: Flush mounting (0" unthreaded) ├── 50: 5.0" (127mm) case length ├── 50: 5m (16.4ft) triaxial cable ├── 02: ClickLoc connector + standard cable └── CN: China GB3836-2010 certified
Model Comparison
| Feature | 330701-00-50-50-02-CN | 330701-00-15-10-02-05 | 330701-00-15-50-01-CN |
|---|---|---|---|
| Case Length | 5.0″ | 1.5″ | 1.5″ |
| Cable Length | 5m | 1m | 5m |
| Certification | China GB | ATEX/IECEx | China GB |
| Best Application | Deep cavity machines | Compact installations | Long-cable needs |
Field Technician Q&A
Q: Suitable for coal mine equipment?
A: Yes – GB certification meets Chinese mining safety standards
Q: Maximum cable extension length?
A: 15m with approved repeaters (signal loss <3dB)
Q: Acceptable for food-grade environments?
A: 304 SST and FEP meet NSF/3-A sanitation requirements
