Description
Bently Nevada 330701-20-30-10-01-05 Multi-Approval Probe
Specialized 11mm sensor with 2″ unthreaded section + 3″ case. Global safety approvals. Made in USA. For critical industrial monitoring.
Model Configuration
- 330701
- 11mm Probe (1/2-20 thread)
- 20
- 2.0″ smooth section
- 30
- 3.0″ case length
- 10
- 1.0 meter cable
- 01
- ClickLoc with protector
- 05
- Multiple global approvals
Performance Data
- Electrical: 5.9Ω ±0.5 resistance
- Thread: 1/2-20 UNF (0.750″ max depth)
- M16 Thread: 24mm engagement
- Bend Radius: 25.4mm minimum
- Temp Range: -51°C to +177°C
Physical Properties
- Tip: PPS plastic
- Body: 304 stainless steel
- Seal: Viton O-ring
- Weight: 0.17kg
Mounting Guide
- Install Torque: 15.2 N•m
- Max Torque: 45.2 N•m
- Connector: Hand-tighten only
- Temp Warning: > -34°C
Compliance & Support
- Multiple international approvals
- US Origin Certificate available
- 12-month defect coverage
Shipping Services
- FedEx International Priority
- UPS Worldwide Express
- DHL Express Worldwide
- Global delivery in 2-5 days
Technical Parameters
- Cable Type: 75Ω triaxial FEP
- Resistance Tolerance: ±0.5Ω
- Seal Pressure: Not factory tested
- Thread Options: 1/2-20 UNF or M16
Common Questions
Q: What is the unthreaded section for?
A: Allows flexible mounting in tight spaces
Q: Which approvals are included?
A: Multiple international safety certifications
Q: Chemical resistance?
A: PPS tip resists most industrial chemicals
Q: Cable replacement possible?
A: No – cable is permanently attached
Q: Express shipping options?
A: Yes – FedEx/UPS/DHL available
