330707-00-10-10-11-00 Bently Nevada 11 mm Probe Fast Delivery

Description

Bently Nevada 3300 XL 11mm Compact Proximity Probe

Complete Product Identification

• Full Product Number: 330707-00-10-10-11-00
  • Base model: 330707 (11mm probe, 5/8-18 UNF)
  • Unthreaded section: 00 (0 inch)
  • Case size: 10 (1.0 inch)
  • Cable length: 10 (1.0 meter / 3.3 feet)
  • Connection: 11 (ClickLoc with protector + FluidLoc)
  • Approvals: 00 (Not required)

Key Performance Data

• Electrical Resistance: 5.9Ω ±0.5Ω
• Temperature Limits: -51°C to +177°C
• Thread Size: 5/8-18 UNF (Max 0.938″ depth)
• Cable Protection: FluidLoc moisture-resistant
• Weight: 0.17 kg (shipping)

Installation Specifications

• Case Torque: Max 45.2 N•m (400 in•lb)
  Recommended 15.2 N•m (133 in•lb)
• Connector Handling: Finger tight only
• Cable Bend Radius: Minimum 25.4mm (1.0 in)
• Temperature Warning: Avoid below -34°C to protect seals

Construction Details

• Tip Material: PPS plastic
• Case Material: 304 stainless steel
• Cable Type: 75Ω triaxial with FEP insulation
• Sealing: Viton O-ring pressure seal

Shipping & Support

• Origin: Made in USA
• Carriers: FedEx/UPS/DHL
• Warranty: 12-month coverage

Professional FAQs

• Q: Is this probe waterproof?
  A: FluidLoc cable resists moisture but isn’t fully waterproof
• Q: Can I use this with 5m systems?
  A: No, 1m probes work only with 1m Proximitor systems
• Q: Does it include installation hardware?
  A: No, only probe and connector protector included
• Q: Pressure rating for oil applications?
  A: Standard Viton seal works, but no pressure tests done
• Q: Accept custom cable lengths?
  A: Only standard 1m, 5m or 9m lengths available
