330708-00-20-10-12-00 Bently Nevada 3300 XL 11 mm Probe Vibration Sensor

Description

Product Brief

• Bently Nevada 3300 XL 11 mm Proximity Probes — precision eddy-current sensor for critical machinery protection.
• Designed for permanent vibration and position monitoring in turbines, compressors, and pumps.
• Robust construction: AISI 304 stainless steel case, PPS tip, and FEP-insulated 75 Ω triaxial cable.
• Wide operating temperature: -51 °C to +177 °C (-60 °F to +351 °F).
• This model: 5/8‑18 UNF thread, unarmored, 1.0 m total length, ClickLoc connector, FluidLoc cable.

Technical specifications

• Brand: Bently Nevada
• Model number: 330708-00-20-10-12-00 (series 3300 XL 11 mm Proximity Probes)
• Measurement range: 2 mm (80 mils) typical, with linearity within ±6 mils for 11 mm systems.
• Frequency response: 0 to 10 kHz (3 dB point) for dynamic displacement.
• Sensitivity (standard): 200 mV/mil (7.87 V/mm) for 3300 XL 11 mm probes.
• Resolution: Infinite (limited by system noise, <0.01 µm typical).
• DC resistance (RPROBE): 5.9 Ω ±0.5 Ω (1 m probe length).
• Temperature range: -51 °C to +177 °C (storage/operating). Avoid below -34 °C for pressure seal integrity.
• Environmental tolerance: Sealed against differential pressure; Viton O‑ring, FEP cable resists oil/chemicals.
• Immunity: 75 Ω triaxial construction rejects EMI/RFI; ClickLoc connector ensures stable signal.

Detailed ordering information

• 330708 = 3300 XL 11 mm probe, 5/8‑18 UNF thread, unarmored
• 00 = Unthreaded length: 0 in
• 20 = Overall case length: 2.0 in
• 10 = Total length: 1.0 m (3.3 ft)
• 12 = Miniature coaxial ClickLoc connector + FluidLoc cable
• 00 = Agency approval: not required

Installation & maintenance

• Mounting thread: 5/8‑18 UNF. Max engagement 0.938 in (23.8 mm).
• Recommended case torque: 15.2 N•m (133 in•lb) — never exceed 45.2 N•m (400 in•lb).
• Connector torque: Finger tight only; max 0.565 N•m (5 in•lb).
• Minimum bend radius: 25.4 mm (1.0 in) — protects cable from kinking.
• Maintenance friendly: ClickLoc connector allows quick replacement without special tools.
• Compatibility: Works with all 3300 XL 11 mm Proximitor sensors and 3500 monitoring systems.

Certification & compliance

• Agency approval option: 00 (not required) – for custom approvals contact Bently Nevada.
• Temperature class (ambient, probe only): T1 to T5 per EPL Ga/Gc; for Dc up to T280°C.
• Designed for use in hazardous areas when combined with appropriate barriers.

Package list & warranty

• Package includes: One 330708-00-20-10-12-00 probe, installation instructions (reference guide).
• Weight: 0.17 kg (shipping).
• Warranty: 12 months against defects in material and workmanship.
• Shipping: FedEx, UPS, DHL available – fast global delivery.

Typical applications & diagnostic ability

• Applications: Radial vibration, axial position, eccentricity, and keyphasor measurements on rotating machinery.
• Diagnostic strength: Detects shaft instability, rubs, misalignment, and bearing wear early.
• Direct interface with Bently Nevada monitors for real-time protection and diagnostics.

Frequently asked questions (FAQ)

• What is the difference between armored and unarmored cable?
  Unarmored (this model) is lighter and more flexible; armored adds mechanical protection for harsh environments.
• Can I use this probe with a 5 m extension cable?
  Yes, but total cable length (probe + extension) must match the proximitor requirements — typically 1, 5, or 9 m total.
• How do I choose the correct total length option?
  Measure distance from probe tip to monitor. Standard options: 1.0 m, 5.0 m, 9.0 m. This part is 1.0 m.
• Is the probe tip replaceable?
  No, the tip is integrally molded with PPS. If damaged, replace the whole probe.
• What if I need a pressure test before installation?
  Standard probes are not pressure tested. Contact our custom department (sales@powergearx.com) for tested units.
• Can I shorten the probe cable?
  Not recommended. Cutting changes resistance and calibration; use exact length ordered.

Buying guide & selection help

• Match thread size (5/8‑18 UNF) to your mounting hole. Other thread options available in the 3300 XL series.
• Select total length based on distance from probe to extension cable. Common choice: 1.0 m (this part).
• For conductive fluid or abrasive environments, consider optional armored cable (not this model).
• Verify agency approval if required for your area (option 00 = none). We can help you find the right certified variant.
• Need a different connector? ClickLoc is standard; other connector styles available – contact us.
