The Bently Nevada 330880-16-00-025-03-02 PROXPAC XL Proximity Transducer is a high-performance solution designed for industrial machinery condition monitoring. This 8 mm proximity probe delivers precise and reliable measurements, ensuring optimal machine protection in harsh environments. Manufactured in the U.S.A., this transducer meets stringent industrial standards, making it an ideal choice for applications requiring robust vibration and displacement monitoring.
Technical Data
- Brand: Bently Nevada
- Model: 330880-16-00-025-03-02
- Probe Type: 3300 XL 8 mm proximity probe (without approvals)
- Standoff Adapter: None (00 Option)
- Probe Penetration: 25 mm (025 Option)
- Fittings: One 3/4-14 NPT fitting, one 3/4-14 NPT to 1/2-14 NPT stainless steel reducer, and two plugs
- Mounting Thread: 3/4-14 NPT
- Weight: 1.44 Kg (3.2 lbs)
Mechanical Specifications
- Housing Rating: IP66, verified by BASEEFA report T07/0709
- Probe Tip Material: Polyphenylene Sulfide (PPS)
- Probe Case Material: AISI 304 Stainless Steel
- Probe Cable: 1-meter length, 75 Ω triaxial, fluoroethylene propylene (FEP) insulated
- Probe Connector: Gold-plated brass ClickLoc
- Housing Strength: Supports 912 N (205 lbf) with the cover fastened
- Housing Impact Strength: Certified to withstand 4 Joule impacts at -39°C to 115°C
- Vibration Isolation Material: Extra Soft Cellular Silicone
