Description
Bently Nevada 3300 NSv M8 Probe: Compact Sensor with FluidLoc Cable
New factory-sealed proximity probe with M8X1 thread. Features chemical-resistant FluidLoc cable for harsh environments. Made in USA with 12-month warranty.
Product Configuration
- Core Model: 330903 (M8X1 thread without armor)
- Unthreaded Length: 00 → 0 mm
- Case Length: 02 → 20 mm
- Cable Length: 10 → 1.0 meter
- Connection: 12 → ClickLoc with FluidLoc cable
- Certifications: 00 → Not required
Key Technical Specifications
- Measurement Range: 1.5 mm (60 mils)
- Accuracy: ±0.06 mm (±2.3 mils) deviation
- Scale Factor: 7.87 V/mm (200 mV/mil)
- Frequency Response: 0-10 kHz (±3dB)
- Target Size: Min 8.9 mm diameter (13mm recommended)
- Cable Resistance: 4.2Ω ±0.5 at 1m
- Field Wiring: Up to 305 meters (1000 ft)
- Temperature Range: -52°C to +177°C
Superior Performance Features
- FluidLoc Cable: Enhanced chemical resistance
- M8X1 Thread: Compact metric installation
- Linear Range: 0.25-1.75mm (10-70 mils)
- Backward Compatible: Works with 3300 RAM systems
- Side-View Performance: Superior to 3000-series probes
Installation Guide
- Recommended Gap: 1.0 mm (40 mils)
- Mounting Torque: 5.1 N•m (45 in•lb)
- Max Torque: 7.3 N•m (65 in•lb)
- Thread Engagement: Max 12 mm
- Cable Bend Radius: Min 25.4 mm (1.0 in)
Package Contents
- 1x M8 threaded probe
- 1x 1m FluidLoc cable
- 1x ClickLoc connector
- Installation guide
- 12-month warranty
Global Shipping
Fast delivery via FedEx, UPS, or DHL with tracking.
Expert Support
Q: What makes FluidLoc cable special?
A: Enhanced resistance to chemicals and fluids in harsh environments.
Q: Can I use this in ATEX zones?
A: This version lacks agency approvals – check certified models for hazardous areas.
Q: Minimum target size?
A: 8.9mm diameter, but 13mm recommended for accurate readings.
Q: How does it compare to older probes?
A: Better chemical resistance and side-view performance than 3300 RAM probes.
Q: What’s the linear range?
A: 0.25-1.75mm (10-70 mils) with best accuracy at 1.0mm gap.
