330903-00-03-05-12-00 Bently Nevada 3300 NSv Proximity Probe

Description

Bently Nevada 3300 NSv Proximity Probe: Precision Industrial Sensing

Description

New & original Bently Nevada 330903-00-03-05-12-00 proximity probe in factory-sealed packaging. Features M8X1 threading, 0.5m FluidLoc® cable, and miniature coaxial ClickLoc connector. Designed for harsh industrial environments with superior chemical resistance and temperature tolerance (-52°C to +177°C). Backed by 12-month manufacturer warranty.

Technical Data

• Brand: Bently Nevada
• Model: 3300 NSv Probe
• Full P/N Suffix: 330903-00-03-05-12-00
• Thread: M8X1 (unarmored)
• Linear Range: 1.5mm (60 mils)
• Accuracy: ±0.06mm deviation
• Output Signal: -1 to -13Vdc
• Temp Range: -52°C to +177°C
• Resistance: 4.0Ω ±0.5Ω (0.5m cable)
• Frequency Response: 0-10kHz (±3dB)

Installation Guide

• Gap Setting: 1.0mm (40 mils) recommended
• Torque: 5.1 N•m (45 in•lb) max
• Thread Engagement: 12mm min
• Bend Radius: >25.4mm (1.0in)

Compatibility

Direct replacement for 3300 RAM probes. Compatible with all Bently Nevada 3300 XL NSv Proximitor systems. Maintains performance with legacy extension cables.

Packaging & Shipping

• Factory-sealed probe
• No certificates included
• Global Shipping: FedEx/UPS/DHL

FAQ

Q: Minimum target size?
A: 13mm (0.5in) diameter for accurate readings

Q: Cable length options?
A: 0.5m (standard), 1m, 5m or 7m available

Q: Pressure rating?
A: Contact for custom pressure testing (Viton® seal standard)
